Linears 12v 180w Triac Dimming LED Driver With Flicker Free Pwm And Dimmable Led Driver

Name: Linears 12v 180w Triac Dimming LED Driver With Flicker Free Pwm And Dimmable Led Driver
Brand: KSPOWER
Price: 43.80 USD

Wholesale Linears 12v 180w Triac Dimming LED Driver With Flicker Free Pwm And Dimmable Led Driver from china suppliers

Place of Origin : Guangdong, China

Brand Name : KSPOWER

Model Number : KSHP-180W12

Certification : UL FCC CE ROHS SAA CLASS P etc.

MOQ : 2 pieces

Price : $43.80/pieces 2-499 pieces

Warranty(Year) : 5-Year

Lighting solutions service : Lighting and circuitry design

Output Power : 180W

Output Type : PWM

Input Voltage : 100-277V

Output Frequency : 50/60Hz

Output Current : 15000 mA

Product Name : 12v180w pwm dimmable LED driver

Dimming : Traic/ Phase-cut,0-10V,1-10V,10V PWM, Resistance (5 in 1)

Output : 12V 180W

Material : Aluminum Case

Warranty : 5 years

Protection : OCP, OVP, SCP, OTP

IP Rate : IP65, IP67

Efficiency : ≥89%

Application : LED Strip Light,Pendants, Linears,Cove Lights

Contact Now

Linears 12v 180w Triac Dimming LED Driver With Flicker Free Pwm And Dimmable Led Driver

Products Description

electron waterproof 12volts180 W Watt lighting transformers constant voltage 12v180w flicker free 5 in 1 pwm dimmable LED driver

KSHP-180W is a versatile 180W 5-in-1 universal dimming driver that accepts 100-277VAC input voltage and provides 12V 24V 36V 48V constant voltage output. KSHP-180W delivers flicker free dimming to 0% on all dinning systems including 0-10V, 1-10V, PWM, Triac/ Phase-cut ,Resistance, MLV, ELV and Incandescent. The high efficiency of the driver and sophisticated overload protection enables the electronics to run cooler and significantly improve reliability while extending product life. The compact metal case is dry/damp location listed and IP67 rated, making it suitable for a wide range of indoor/outdoor architectural, commercial, industrial, and residential lighting applications. KSHP-180W is available with or without integrated junction boxes on both the input and output side that have two knock outs each.

Features:
* Input Voltage: Universal 100VAC to 277VAC, 50/60Hz for Residential, Commercial, and Industrial Use
* Single Channel & Constant Voltage mode
* Output Voltage: 12Volt/24Volt/36Volt/48Volt
* Driver Type: Class 2 Class P
* Enclosure:LISTED Enclosure with Junction Box / LISTED Enclosure without Junction Box
* Dimming: Triac/ Phase-cut, PWM, 0/1-10V or MLV / ELV Resistance Dimmable Available
* Environmental: Dry and Damp
* Wiring Compartments with Knock-Outs for Clean and Easy Installation
* Current Limiting Overload Protection
* Flicker-Free
* Smooth Ripple Free Output Voltage
* IP67 Rated Enclosure for Indoor and Outdoor Use
* 5-Years Warranty
* UL/cUL CE FCC RoHS ENEC GS Listed, SELV, Type HL

Note:Any custom label/package/case is acceptable, provide OEM and ODM service

Input Voltage	100~277V AC 47~63Hz
Power Factor	PF≧0 98/115VAC, PF≧0 95/230VAC, PF≧0.9/277VAC, 80% with load
NO.	KSHP-180W12	KSHP-180W24	KSHP-180W36	KSHP-180W48
Output Voltage	12V	24V	36V	48V
Rated Current	15A	7.5A	5A	3.75A
Rated Power	180W
Ripple & Noise (max.)	200mVp-p	250mVp-p	250mVp-p	250mVp-p
Dimension(LWH)	3436841mm / 13.52.681.83in

Show Details

Company Profile

Working Room

Specification:

Nearly ¥3 Million Is Spent On Certification, Just To Make Customers Trust Our Quality

Exhibition

Product packaging

1.Sample is available.

2.Shipping method: available for express DHL/UPS/FedEx/TNT, Land, Ocean and others.
3. for 60W power adapter : each one put in one small inner brown box, then 50 pcs put in one standard carton.

Package	Piece/Carton(pcs)	Piece Weight(KG)
OEM package	50	0.26
Dimension/Brown Box(mm)	Dimension/Carton(mm)	Gross Weight/Carton(KG)
1558535	455370175	14
